| FRF-125 | FRF-145 | BRF-160 | FRF-165 | BRF-180 | BRF-200 | |
|---|---|---|---|---|---|---|
| Product Family | Offset Flail Mowers | Offset Flail Mowers | Offset Flail Mowers | Offset Flail Mowers | Offset Flail Mowers | Offset Flail Mowers |
| Product | FRF-125 | FRF-145 | BRF-160 | FRF-165 | BRF-180 | BRF-200 |
| Description | FRF-125 Offset Flail Mower | FRF-145 Offset Flail Mower | BRF-160 Offset Flail Mower | FRF-165 Offset Flail Mower | BRF-180 Offset Flail Mower | BRF-200 Offset Flail Mower |
| Notes | Available with Hammers only | Available with Hammers only | Available with Hammers only | Available with Hammers only | Available with Hammers only | Available with Hammers only |
| Offset | Offsets to the right | Offsets to the right | Offsets to the right | Offsets to the right | Offsets to the right | Offsets to the right |
| Degree of Tilt | 90 degrees up and 65 degrees down | 90 degrees up and 65 degrees down | 90 degrees up and 65 degrees down | 90 degrees up and 65 degrees down | 90 degrees up and 65 degrees down | 90 degrees up and 65 degrees down |
| Quantity of Rear Remotes Needed | 2 Sets | 2 Sets | 2 Sets | 2 Sets | 2 Sets | 2 Sets |
| HP Required | 20-40 hp | 30-45 hp | 70-100 hp | 40-50 hp | 70-100 hp | 70-100 hp |
| Working Width | 47" | 55" | 63" | 63" | 71" | 79" |
| # of Hammers | 20 | 24 | 14 | 28 | 16 | 16 |
| Hammer Size | 3.4" x 1.7" | 3.4" x 1.7" | 4.9" x 1.7" | 3.4" x 1.7" | 4.9" x 1.7" | 4.9" x 1.7" |
| Side Transmission | 3 Belts | 3 Belts | 4 Belts | 4 Belts | 4 Belts | 4 Belts |
| Roller Thickness or Diameter | 4.7" | 4.7" | 7.6" | 4.7" | 7.6" | 7.6" |
| Rotor Thickness or Diameter | 4.2" | 4.2" | 6.3" | 4.2" | 6.3" | 6.3" |
| Weight (lbs) | 630 lbs | 672 lbs | 1433 lbs | 703 lbs | 1565 lbs | 1719 lbs |
| PTO Drive Shaft | Series 4 | Series 4 | Series 6 | Series 4 | Series 6 | Series 6 |
