Description
Specs
| 2510 | |
|---|---|
| Product Family | 2510 Series |
| Product | 2510 |
| Description | 10' Flex-Wing Cutter |
| RPM | 540 |
| HP Required | 25 – 60 PTO |
| Working Width | 123" |
| Overall Width | 132" |
| Transport Width | 96.5" |
| Tongue Weight | 830 lbs |
| Weight (lbs) | 2400 lbs with 4-20" Laminated Tires |
| Cutting Height | 1-3/4" to 11-1/2" |
| Cutting Capacity | up to 2" |
| Deck Thickness | 11 GA |
| Deck Height | 11" |
| Side Bands | 7 GA |
| Suspension | 1 Medium Duty Spring in Center Tailwheel Assembly |
| Skid Shoes | Replaceable |
| PTO Drive Shaft | ASAE CAT 5 |
| Wing Drive PTO | ASAE CAT 4 |
| Driveline Protection | Slip Clutch |
| Blade Holder | Round Stump Jumper |
| Gearbox Rating | 175 HP |
| Outboard Gearbox Rating | 75 HP |
| Wing Flex | 20 Degrees Down to 85 Degrees Up |
| Blades | 1/2" x 3" Uplift |
| Blade Overlap | 5-1/4" |
| Wheel Type | 20" Laminated |
| Hitch Type | Swivel Pivot Self Leveling |
| Gearbox Warranty | 5 Year Limited |
| Safety Tow Chain | Standard |
| Guarding Options | Single Row Chains Standard |
| FPM | 14600 |
