IDEAL Rotary Tiller

Ideal Farm Equipment’s Rotary Tiller can take on the big jobs, able to handle acres of dirt with no worries. This implement boasts thick-steel cutting tines that work hard to break up and mix hardened soil into soft, workable land. The tines can be adjusted to three depth levels, perfect for landscaping, gardening and nurseries.


For more product information or to place an order please contact us.

Get More Information
Have Questions? Call 330-674-0495

For financing information Click Here

Description

RT4LDID RT5SDID RT6SDID

Recommended Tractor PTO HP

15 – 35

25 – 50

30 – 50

Weight (lbs.)

470

638

718

Working Depth

7″

7″

7″

Working Width

46.5″

58.75″

70.59″

Overall Width

51.5″

64″

76″

Hitch

Limited Cat 1, Quick Hitch Compatible

Cat 1, Quick Hitch Compatible

Cat 1, Quick Hitch Compatible

Driveline

540 RPM Slip Clutch Protection

540 RPM Slip Clutch Protection

540 RPM Slip Clutch Protection

Number of Rotor Flanges

6

7

9

Number of Tines per Flange

4

6

6

Rotor Rotation

Reversible (FWD/REV)

Reversible (FWD/REV)

Reversible (FWD/REV)

Rotor Shaft Speed

211 RPM @ 540 RPM PTO

211 RPM @ 540 RPM PTO

211 RPM @ 540 RPM PTO

Skid Shoes

Adjustable (0.4″, 1.4″, 2.4″)

Adjustable (0.4″, 1.4″, 2.4″)

Adjustable (0.4″, 1.4″, 2.4″)

Top Gearbox Construction

Cast Iron Housing, Precision Forged Steel Gears

Cast Iron Housing, Hardened Steel Gears

Cast Iron Housing, Hardened Steel Gears

Side Drive Construction

Formed Steel Housing, Hardened Steel Gears

Formed Steel Housing, Hardened Steel Gears

Formed Steel Housing, Hardened Steel Gears

Top Gear Box Lubrication

EP 80-90W Gear Oil

EP 80-90W Gear Oil

EP 80-90W Gear Oil

Side Drive Lubrication

EP 80-90W Gear Oil

Major Construction

3/8″ Solid Steel Gearbox Plate and End Plates, 5/8″ Steel Hitch Frame

3/8″ Solid Steel Gearbox Plate and End Plates, 5/8″ Steel Hitch Frame
